Summary for EVELO Atlas E-Bike
The EVELO Atlas is a remarkable e-bike designed by John O’Donnell, the director of product development at EVELO. Known for its robust and custom features, the Atlas stands out with its unique breakaway frame that accommodates a Gates carbon belt drive, ensuring a cleaner and more durable ride. This bike is equipped with a Nuvinci Enviolo CVT transmission, offering an impressive 380% gear range comparable to an 11-42 tooth cassette. The mechanical shifting system allows for smooth transitions even at a standstill, enhancing the overall riding experience.
The Atlas boasts a 110mm travel air suspension fork made from hard anodized aluminum alloy, providing high adjustability and a smooth ride. With 34mm stanchions and boost hub spacing, it supports 27.5 by 2.8-inch plus-size tires that contribute to added comfort, stability, and a lower attack angle. Despite being designed as a city model with fenders, integrated lights, and an optional rear rack, the Atlas can easily transform into a cross-country electric bike with a simple tire swap.
Powering the Atlas is the Bafang M600 mid-drive motor, producing up to 120 Nm of torque. This high-powered yet smooth motor is custom programmed for a progressive riding experience, suitable for both recreational and mountain biking. The bike comes throttle-ready, although it ships as a Class 3 e-bike with a top speed of 28 mph. It features a USB charging port on the display, allowing riders to keep their devices charged on the go.
The EVELO Atlas is only available in one frame size and a sleek satin black color. The bike’s weight, including the battery, is approximately 66.2 pounds, with the battery alone weighing 8.5 pounds. This model features plastic fenders mounted securely to the suspension fork and a speed sensor for accurate performance tracking. The dynamic motor supports up to 110 RPM pedal support, ensuring consistent power delivery even during fast pedaling.
Comfort is a priority with the Atlas, featuring a 31.6mm seat post diameter and a 350mm height, which can be upgraded to a suspension seat post for added comfort. The saddle is the Selle Royal Shadow Plus, providing a plush riding experience. The bike’s ergonomic, custom-made rubber grips and hydraulic disc brakes with motor inhibitors enhance safety and control.
The Atlas utilizes CAN bus communications for precise electronic interactions between the battery, motor, and display. The bike comes with a comprehensive four-year warranty, covering everything except the battery, which has a two-year warranty with a prorated period extending to four years. Priced at $4,699, the Atlas includes a bottle cage and a convenient plastic holster. Integrated lights with brake light activation, a sturdy rear rack, and a secondary battery option for extended range are additional highlights of this versatile e-bike.
EVELO Atlas E-Bike Information
- Range: Up to 70 miles
- Top Speed: 28 mph
- Motor Size: Bafang M600, 600W nominal, 1200W peak
- Battery Size: 720Wh primary battery, optional secondary battery
- Frame: Custom designed, aluminum alloy
- Warranty: Comprehensive four-year warranty, two years on the battery with prorated extension
- Safety Certified: Yes
- Digital Display: Yes, with USB charging port
Full Specifications of EVELO Atlas
- Miles Per Charge: Up to 70 miles
- Max Speed: 28 mph
- Max Rider Weight: 350 lbs
- Waterproof Rating: IP65
- Motor Size: Bafang M600, 600W nominal, 1200W peak
- Battery Size: 720Wh
- Tire Size: 27.5″ x 2.8″
- Product Weight: 66.2 lbs with battery
- Dimensions: 17.5″ frame size
- Warranty Length: Four years comprehensive, two years on the battery with prorated extension
- Frame Material: Aluminum alloy
- Color(s): Satin black
- Inner Tubes: Standard 27.5″ compatible
- Brakes: Hydraulic disc brakes with motor inhibitors
- Charge Time: Approximately 4-6 hours
- Suspension: 110mm travel air suspension fork
- Display: Digital display with USB charging port
- Headlight: 400 lumens with side visibility
- Charger: 3A charger, weighs 1.5 lbs
